FC/PC Multimode Connector 0.9mm/2.0mm/3.0mm Boot 200pcs/pack

$78.00

Each pcs=USD0.39/pc

Description

The FC connector is used extensively in the telecommunications market, where long single mode optical fiber cables can run upwards of 50km.  In these extreme situations the connector needs to have extremely low loss and accurate geometry. The Optronics FC Optical Fiber connector comprises of a nickel plated brass body and a ceramic ferrule/spring/crimp barrel assembly plus a crimp over sleeve and rubber boot.  These connectors are suitable for 900µm and 2mm and 3mm cables. The connector is precision made and manufactured to demanding specifications. The combination of a ceramic ferrule and a precision nickel plated brass housing provides consistent long-term mechanical and optical performance. The Optronics FC connector is available in Single mode PC and APC versions as well as multi mode

Specifications

Boot Size 0.9mm 2.0mm 3.0mm
Ferrule Size 125.0µm 125.5µm 126.0µm 127.0µm 125.3µm 128.0µm
Boot color Black Blue Green Yellow
Boot Type slotted boot smooth boo
Optical Performance
Single mode Insertion loss Max. 0.3 dB Typical 0.2 dB
Return Loss UPC > 50dB Typical 55 dB APC > 60dB Typical 65 dB
Multimode Insertion loss Max. 0.3 dB Typical 0.12 Db (IEC 874-1 method)
Vibration (Mated Pair) (IEC 61300-2-1) 10-55 Hz, =0.3dB Change 1.5mm P to P
Mating Durability (IEC 61300-2-2) 1000 mating cycles Clean every 25 < 0.2 dB Change
High Temperature (IEC 61300-2-18) 75°C for 96 hours =0.2dB Change
Damp Heat (IEC 61300-2-19) 60°C at 95% RH, 96 hours =0.2dB Change
Temperature Cycling (IEC 61300-2-48) -40 to +85°C, 42 cycles =0.2dB Change
Operating Temperature -40°C to +85°C
