4 Fiber FTTH Compact Terminal Box Fiber Optical Junction Box HY-20-T-4C

$3.20

Description

Mini FTTH 4 Port Terminal Box

Description:

GH’s 4 Port FTTH Box is a FTTH terminal box, made of ABS plastic,

1 inlet ports and 4 outlet ports, can be installed PLC splitter, suitable for

indoor and outdoor wall or hanging rods use. It is available for the distribution and terminal connection for various

kinds of optical fiber system, especially suitable for mini-network terminal

distribution, in which the optical cables, patch cores or pigtails are connected.

Feature:

  • small size, light weight, high capacity, easy to installation;
  • Industry Standard User Interface, be made of high impact plastic;
  • UV resistant and weather proof;
  • Up to 4 drop cable;
  • 1 inlet port( for cables with max diameter 12mm), 4 outlet ports;
  • Wall mounting or pole mounting ;
  • Suitable for 4 pcs SC simplex adapters or 4 pcs LC duplex adapters ;
  • Reasonable inner space design;
  • Protect optical fiber;
  • Realize FTTH(fiber to the desktop)system and provide users with optical access or data access;
  • Used in FTTH indoor application, home or work area;
  • ROHS compliance.

Specification:

Item Characteristic
Dimension(L*W*H) 210x140x40mm
Cable Diameter(mm) Φ 7~Φ 10
Adaptor 4XSC simplex,4X LC duplex
Color white
Material ABS
Net Weight 257g
Operation Temperature -20oC to + 50oC
Cable Ports 1+4
Max Capacity of Splice 4(single fiber)
Protection Class IP67

Order Information: HY‐20‐T‐4C
